Manufacturer: Temco Controls
Product:
Model: T3E-886
Class: MODBUS
Updated: 2025-08-11

Registers

#	Name	Unit
1	Input 1	.
2	Input 2	.
3	Input 3	.
4	Input 4	.
5	Input 5	.
6	Input 6	.
7	Input 7	.
8	Input 8	.
9	Relay 1	.
10	Relay 2	.
11	Relay 3	.
12	Relay 4	.
13	Relay 5	.
14	Relay 6	.
15	Analog out 1	V
16	Analog out 2	V
17	Analog out 3	V
18	Analog out 4	V
19	Analog out 5	V
20	Analog out 6	V
21	Analog out 7	V
22	Analog out 8	V
23	Sw DO1	.
24	Sw DO2	.
25	Sw DO3	.
26	Sw DO4	.
27	Sw DO5	.
28	Sw DO6	.
29	Sw AO1	.
30	Sw AO2	.
31	Sw AO3	.
32	Sw AO4	.
33	Sw AO5	.
34	Sw AO6	.
35	Sw AO7	.
36	Sw AO8	.

Notes

Temco Control's T3E-886 I/O expander.

 6 relay outputs
 8 analog outputs (0-10V)
 8 analog inputs (0-10V, 4-20mA, Thermistor or on/off)

Supports Modbus/RTU and /TCP

Connect (RTU):
ezeio D0 -> 485-
ezeio D1 -> 485+
ezeio 0V -> GND
ezeio +V -> Power+ (optional)

Default address 254, 19200bps

Write to holding register 6 to change address/unit
Write to holding register 15 to change speed
0=9600, 1=19200

Notes:
- When using /TCP, the /RTU address is the unit.
- When in 4-20mA mode, the inputs switch in the shunt resistor for 50ms every 450ms. Loop powered deviced may have an issue with this.
- The /RTU bus will sometimes miss a message shortly after the output state change.
- Output switches must be in the "A" position for remote control
